Digisat make 9.0 mtr Earth Station Antenna

Description

Digisat make ( make in India ) 9.0 mtr cassegrain design Antenna delivers exceptional high performance for transmit /receive application in C ,Ku, ka in TX/Rx 2 port ,4 port with high gain ,low noise and low microwave interference. Digisat 9.0 mtr Antenna offers a fine reflector design with a stretch formed double contoured panels, strong back struts and hub for ease of field alignment. The standard designed azimuth over elevation Pedstal provides a cost-effective solution for ground or roof installation with high stiffness and stability, full orbital arc coverage and fine drive performance, and ensures the pointing and tracking accuracy. The electrical performance is compliant with FCC and ITU-RS-580 side lobe specifications & compliance with/MPVT NOCC test, SES , intelsat, Asiasat, theicom, etc. requirement.

Performance strength

• C, Ku, multi band, extended band available, meeting FCC and ITU-RS-580 requirements.
• High quality aluminum reflector panels and galvanized steel backup structure.
• Self-aligning aluminum antenna reflector-no field alignment
• Galvanized steel elevation over azimuth pedestal.
• Fixed foundation and Non penetrating foundation optional for wider choice.
• Survives 125 mph winds in any position and High wind configuration optional.
