Digisat make 7.3 mtr Earth Station Antenna

Description

Digisat make ( make in India ) 7.3m antenna delivers exceptional high performance for transmit/receive application in C ,Ku, ka, X band in Tx/Rx 2 ports, 4 ports or Rx 2 port with high gain ,low noise and low microwave interference. Digisat 7.3m antenna offers a fine reflector design with a stretch formed double contoured panels, strong back struts and hub for ease of field alignment. The standard designed azimuth over elevation pedestal provides a cost-effective solution for ground or roof installation with high stiffness and stability, full orbital arc coverage and fine drive performance, and ensures the pointing and tracking accuracy.

Performance strength

• Meets or exceeds CCIR 580 and meeting FCC and ITU-RS-580 requirements.
• High G/T, excellent pattern characteristic.
• Hot dip zinc steel pedestal, hub & back struts.
• Galvanized stainless steel fasteners.
• Foundation hardware kit provided.
• Package suitable for air, ocean land transportation.
