Digisat make 3.8 mtr Antenna

Description

Digisat 3m antenna delivers exceptional high performance for transmit/receive application in C ,Ku, ka, X band in Tx/Rx 2 port or Rx 2 port with high gain ,low noise and low microwave interference. Digisat 3m antenna offers a fine reflector design with a stretch formed double contoured panels, strong back struts and hub for ease of field alignment. The standard designed azimuth over elevation pedestal provides a cost-effective solution for ground or roof installation with high stiffness and stability, full orbital arc coverage and fine drive performance, and ensures the pointing and tracking accuracy.

Performance strength

• High quality aluminum reflector panels and galvanized steel backup structure.
• C, Ku, Ka, X band available, meeting FCC and ITU-RS-580 requirements.
• Galvanized steel elevation over azimuth pedestal.
• Fixed foundation and Non penetrating foundation optional for wider choice.
• Survives 125 mph winds in any position and High wind configuration optional.
